From ISO 20022 data mapping and message transformation to payment status integration
The Bank of Korea is preparing to begin pilot operations of the Bank of Korea Won International Wire Network in September 2026. The network is designed to operate 24 hours on business days, excluding weekends and public holidays.
For foreign financial institutions preparing to participate in the new KRW settlement environment, one of the most important implementation questions is:
How can an existing payment system be connected to the Bank of Korea Won International Wire Network?
Financial institutions do not necessarily need to replace their existing payment infrastructure.
The key is to establish an integration layer that can map existing transaction data to ISO 20022 messages, exchange the required financial messages, and return processing and settlement results to the institution’s existing systems.
A typical integration flow can be summarized as follows:
Existing Payment System → Data Mapping → ISO 20022 Message Generation & Transformation → Message Exchange → Processing Result Integration
What Is Required to Connect to the Bank of Korea Won International Wire Network?
Connecting to the new network involves more than simply generating ISO 20022 messages.
Each financial institution operates different payment systems, data structures, transaction workflows, and internal processing rules.
Before implementation, institutions need to identify:
- where payment instructions are generated;
- which systems maintain transaction information;
- how account and financial institution information is managed;
- where payment status is stored;
- which data needs to be transmitted to the Bank of Korea network; and
- how processing and settlement results should be returned to existing systems.
The objective is to determine how the institution’s current payment environment can be connected to the new network with the minimum necessary changes.
Can Existing Payment Systems Be Used for Bank of Korea Integration?
Yes. In many cases, financial institutions can continue using their existing payment systems.
A connection to the Bank of Korea Won International Wire Network does not automatically require a complete replacement of the institution’s payment infrastructure.
Instead, the existing system can be retained while an integration layer handles communication between internal payment systems and the Bank of Korea network.
For example, institutions may already manage information such as:
- account details;
- transaction amounts;
- financial institution identifiers;
- payment references;
- internal transaction IDs; and
- transaction status.
However, the structure and format of this information may differ significantly from the ISO 20022 messages required for external settlement.
The integration process must therefore determine which internal data should be transmitted, how it should be transformed, and where the resulting settlement status should be reflected.
Is Generating an ISO 20022 Message Enough?
No.
ISO 20022 defines a standardized structure for exchanging financial information, but it does not automatically transform data from an institution’s existing systems.
Existing transaction data must first be mapped to the appropriate ISO 20022 message elements.
This process is known as data mapping.
ISO 20022 data mapping is not simply a matter of matching field names.
Financial institutions need to review:
- the business meaning of each data element;
- mandatory and conditional fields;
- data formats and lengths;
- code values;
- validation requirements; and
- the relationship between the original transaction and each ISO 20022 message.
The business messages used for the Bank of Korea network also include a Business Application Header (BAH) together with the relevant ISO 20022 message body.
The BAH provides information required to identify and process the message, including information related to the sending institution, receiving institution, message type, and message identification.
Therefore, there is a significant difference between:
“Can our system generate ISO 20022 messages?”
and
“Can our existing payment system operate end to end with the Bank of Korea Won International Wire Network?”
For a production environment, the second question is far more important.
How Does ISO 20022 Data Mapping Work?
The first step is to analyze the transaction data currently generated by the institution’s payment systems.
Each internal data element must then be mapped to the corresponding field required by the Bank of Korea network.
For example, information such as transaction amount, account details, financial institution identifiers, references, and transaction IDs may need to be transformed into the appropriate ISO 20022 structure.
During this process, institutions must also consider how to handle:
- missing mandatory data;
- different internal code structures;
- character and format restrictions;
- validation errors;
- message identifiers; and
- transaction references used to match responses.
A well-designed mapping structure helps reduce the amount of change required in existing payment systems while allowing the new ISO 20022 environment to operate as part of the institution’s existing workflow.
How Are Payment and Settlement Results Integrated?
Integration does not end when a payment message is transmitted.
The response from the network must also be processed and connected back to the institution’s existing transaction workflow.
For example, in a customer credit transfer scenario, a pacs.008 payment instruction may be transmitted and a pacs.002 payment status message may subsequently be received.
The institution’s system must then determine:
Which original transaction does this response belong to?
The response must be matched to the correct transaction, and the corresponding processing or settlement status must be updated in the existing payment system.
Institutions must also prepare for situations in which:
- an expected response is not received;
- the processing status of a transaction must be checked;
- a previous message needs to be retransmitted;
- a message is rejected because of validation errors; or
- an operational exception requires investigation.
The messaging framework includes procedures for these scenarios, including the use of messages such as pacs.028 for transaction status inquiries and admi.006 for message retransmission procedures.
This means the integration scope should cover not only message generation and transmission, but also:
response processing, transaction matching, status management, exception handling, and error management.
What Does a Typical Integration Architecture Look Like?
Although the exact implementation depends on each institution’s system environment, the overall process can be structured as follows:
1. Existing System Analysis
Identify where payment instructions, transaction data, account information, and payment status are currently managed.
2. Data Mapping
Map existing transaction data to the required ISO 20022 message elements.
3. ISO 20022 Message Generation & Transformation
Transform internal transaction data into the required ISO 20022 message format.
4. Message Validation & Exchange
Validate messages according to required rules and exchange them with the Bank of Korea network.
5. Processing Result Integration
Receive payment and settlement responses and match them to the appropriate original transactions.
6. Transaction Status & Error Management
Update transaction status in existing systems and manage exceptions, errors, inquiries, and retransmissions.
The important point is that these functions should not operate independently.
They must work together as part of an end-to-end payment workflow.
What Should Foreign Financial Institutions Prepare?
Foreign financial institutions considering participation in the Bank of Korea Won International Wire Network should begin by reviewing their existing payment architecture.
Key questions include:
- Where are KRW payment instructions currently generated?
- Which system contains the data required for ISO 20022 messages?
- Can existing data be mapped to the required message structure?
- How will messages be validated and transmitted?
- How will pacs.002 and other responses be matched to existing transactions?
- How will transaction status be updated internally?
- How will missing responses, rejected messages, and exceptions be managed?
- Which existing systems can remain unchanged?
Answering these questions early can help define the actual scope of the integration project.
It can also help institutions avoid unnecessary changes to core payment systems.
Why Is an Integration Layer Important?
For many financial institutions, replacing an existing payment platform simply to support a new external network would create significant cost, complexity, and operational risk.
An integration layer provides another approach.
It can sit between existing financial systems and the Bank of Korea network and handle:
Data Mapping → ISO 20022 Transformation → Message Exchange → Response Processing
This allows the institution’s existing payment infrastructure to continue operating while adding the capabilities required to support the new KRW settlement environment.
The result can be a more practical implementation approach with less disruption to existing operations.
Connecting Existing Financial Systems to the Bank of Korea Won International Wire Network with INSPIEN
INSPIEN has extensive experience connecting enterprise systems with external organizations and business networks through EDI and system integration technologies.
Based on this integration expertise, INSPIEN supports financial institutions preparing to connect their existing payment environments to the Bank of Korea Won International Wire Network.
Depending on the institution’s current architecture and requirements, the integration scope can include:
Existing System Analysis → Data Mapping → ISO 20022 Message Generation & Transformation → Message Exchange → Processing Result Integration
The objective is not to replace an institution’s entire payment infrastructure.
Instead, INSPIEN helps financial institutions leverage their existing systems while implementing the additional integration capabilities required for the new KRW settlement environment.
For foreign financial institutions, this approach can help minimize unnecessary changes to core payment environments while establishing the message transformation, connectivity, and operational integration required for Bank of Korea settlement.
Frequently Asked Questions
Do financial institutions need to replace their existing payment systems?
Not necessarily.
Existing payment systems can often be retained while an integration layer handles ISO 20022 message transformation, communication with the Bank of Korea network, and processing result integration.
What is required for ISO 20022 integration?
Typical requirements include existing system analysis, data mapping, ISO 20022 message generation and transformation, message validation, message exchange, processing result integration, transaction status management, and exception handling.
What is ISO 20022 data mapping?
ISO 20022 data mapping is the process of connecting transaction data from an institution’s existing systems to the corresponding elements of an ISO 20022 message.
It includes not only field mapping, but also data formats, mandatory fields, code values, validation requirements, and business meaning.
How are payment status messages connected to existing systems?
When a payment status message such as pacs.002 is received, the integration system identifies the corresponding original transaction and updates its processing or settlement status in the institution’s existing payment system.
Can INSPIEN support integration without replacing the existing payment infrastructure?
Yes.
INSPIEN focuses on connecting existing financial systems to the Bank of Korea Won International Wire Network through data mapping, ISO 20022 message transformation, message exchange, and processing result integration.
Preparing for Bank of Korea ISO 20022 Integration?
If your institution is preparing to connect to the Bank of Korea Won International Wire Network and is evaluating:
- how to connect an existing payment system;
- how to map existing transaction data to ISO 20022;
- how to implement message generation and transformation;
- how to integrate processing and settlement results; or
- how much of the existing payment infrastructure needs to change,
INSPIEN can help assess the appropriate integration scope based on your current system environment.
Talk to INSPIEN about your Bank of Korea Won International Wire Network integration requirements.
